Brand: Oakton
Product Code: 147-04
Availability: Call for availability

Features

  • Small footprint saves bench space
  • Direct readout of ion concentration in ppm
  • Oversized dual display for easier viewing
  • Features 0.1 mV resolution for ORP measurements
  • Simultaneous display of ppm and mV electrode output in the ion mode
  • Selectable buffer sets and five-point pH calibration with auto buffer recognition
  • Works with many ion-selective electrodes
  • Built-in electrode stand
  • Selectable manual or automatic temperature compensation
  • Built-in memory function
  • Hold function, “Ready” indicator, diagnostic messages
  • Slide-out instruction card for quick reference

Specifications

  • Measuring Parameters: ph, mV, Ion concentration, Temperature
  • pH:
    • Range: -2.00 to 16
    • Resolution: 0.01
    • Accuracy: ±0.01
    • Calibration: Up to 5 points
  • Millivolt:
    • Range: ±2000 mV
    • Resolution: 0.1 mV from ±199.9 mV
    • Accuracy: 1 mV beyond ±199.9 mV
    • Calibration: Offset up to ± 150 mV
  • Ion:
    • Range: 0.01 - 2000 ppm
    • Resolution: 0.01 ppm / 0.1 ppm / 1 ppm
    • Accuracy: ±0.5% of reading (monovalent) ±1.0% of reading (divalent)
    • Calibration: From 2 to 5 points
  • Temperature:
    • Range: 0.0° - 100.0°C (32° - 212°F)
    • Resolution: 0.1°C (0.1°F)
    • Accuracy: ±0.3°C (±0.5°F)
    • Calibration: Offset 0.1°C Increments
    • Temperature Compensation Automatic or Manual, 0 - 100°C

Part Number

  • #147-04
